Ekspansionsåbninger |
1 x PCIe 4.0/3.0 x16 (x16 mode)
1 x PCIe 3.0 x16 ( x4 mode)
1 x PCIe 3.0 x1 |
|
Grænseflade (lagring) |
1 x M.2 Socket 3, with M Key, type 2242/2260/2280 (SATA & PCIE mode)
1 x M.2 Socket 3, with M Key, type 2242/2260/2280/22110 (SATA & PCIE mode)
4 x SATA 6Gb/s port(s) |
|
Interne interfaces |
1 x CPU Fan connector
1 x CPU OPT Fan connector
2 x Chassis Fan connectors
2 x Aura RGB Strip Headers
1 x Addressable Gen 2 header(s
1 x USB 3.2 Gen 1 Header
2 x USB 2.0 Header
1 x SPI TPM header
1 x Front panel audio connector |
|
Interface |
1 x PS/2 keyboard/mouse combo port
1 x DisplayPort
1 x HDMI
1 x LAN (2.5G) port
2 x USB 3.2 Gen 2 (teal blue) (1 x Type-A+1 x USB Type-C®)
2 x USB 2.0 4 x USB 3.2 Gen 1 (blue) (one port can be switched to USB BIOS FlashBack™)
1 x Optical |
|
Strømkontakter |
1 x 24-pin EATX Power connector(s) 1 x 8-pin EATX 12V Power connectors |
| Diverse |
|
Bredde |
395 mm |
|
Dybde |
244 mm |
Yderligere information
| Ekstern beskrivelse (URL) |
https://www.asus.com/Motherboards/TUF-GAMING-B550M-PLUS/ |
| Specifications Widget |
Specifikationer
| Generelt |
|
Sokkel |
AM4 |
|
Formfaktor |
M-ATX |
|
Chipsæt |
B550 (AMD 3-5000 Series) |
|
Kompatible processorer |
AMD Ryzen™ 5000 Series/ 4000 G-Series/ 3000 Series Desktop Processors |
| Ram |
|
RAM Teknologi |
DDR4 |
|
Ram Bus Clock |
4600(O.C)/4400(O.C)/4266(O.C.)/4133(O.C.)/4000(O.C.)/3866(O.C.)
3733(O.C.)/3600(O.C.)/3466(O.C.)/3333(O.C.)/3200/3000/2800/2666/2400/2133 |
|
Antal RAM slots |
4 |
|
Maks. RAM kapacitet |
128 GB |
| Ekspansion |
|
Ekspansionsåbninger |
1 x PCIe 4.0/3.0 x16 (x16 mode)
1 x PCIe 3.0 x16 ( x4 mode)
1 x PCIe 3.0 x1 |
|
Grænseflade (lagring) |
1 x M.2 Socket 3, with M Key, type 2242/2260/2280 (SATA & PCIE mode)
1 x M.2 Socket 3, with M Key, type 2242/2260/2280/22110 (SATA & PCIE mode)
4 x SATA 6Gb/s port(s) |
|
Interne interfaces |
1 x CPU Fan connector
1 x CPU OPT Fan connector
2 x Chassis Fan connectors
2 x Aura RGB Strip Headers
1 x Addressable Gen 2 header(s
1 x USB 3.2 Gen 1 Header
2 x USB 2.0 Header
1 x SPI TPM header
1 x Front panel audio connector |
|
Interface |
1 x PS/2 keyboard/mouse combo port
1 x DisplayPort
1 x HDMI
1 x LAN (2.5G) port
2 x USB 3.2 Gen 2 (teal blue) (1 x Type-A+1 x USB Type-C®)
2 x USB 2.0 4 x USB 3.2 Gen 1 (blue) (one port can be switched to USB BIOS FlashBack™)
1 x Optical |
|
Strømkontakter |
1 x 24-pin EATX Power connector(s) 1 x 8-pin EATX 12V Power connectors |
| Diverse |
|
Bredde |
395 mm |
|
Dybde |
244 mm |
